OSSDEN, K35 Sliding Gate Opener (1800kg), Premium Sliding Gate Automation Solution
OSSDEN, K35 Sliding Gate Opener (1800kg), Premium Sliding Gate Automation Solution - Image 2
OSSDEN, K35 Sliding Gate Opener (1800kg), Premium Sliding Gate Automation Solution - Image 3
OSSDEN, K35 Sliding Gate Opener (1800kg), Premium Sliding Gate Automation Solution - Image 4

OSSDEN, K35 Sliding Gate Opener (1800kg), Premium Sliding Gate Automation Solution

K35 using advanced technology, this gate opener is an overheating protector, its smooth operation and easy installation will better satisfy your needs, with turbine and turbine rod transmission structure, manual clutch will be conducted when power is failed.

Buy Now on WhatsApp Watch Video
Categories: ,
  • 1 x Gate Motor
  • 2 x Remote Controls
  • Brackets, Fittings & Hardware
  • Instruction Manual
  • Control Box
  • Clutch Key
  • 1X Set Screw
  • Optional Components: Alarm Lamp, Infrared ray, Back-up supply, Bluetooth, Vehicle Remote Control, Mobile Phone Visual Control, WIFI….etc

Feature:

  • Overheating protector
  • Smooth operation, Easy installation
  • Transmission structure of turbine and turbine rod
  • Manual clutch when power failure



Technical Data Sheet:

Input Voltage:AC220V
Power:75OW
Rotation Speed:1400rpm
Torque:35Nm
Running Speed:12 m/min
Max. Gate Weight:1800KG
Temperature:-45°C~+65°C
Noise:<56dB
Dimension of Gate Opener:305*200*155mm
Carton Size:320*270*375mm
Packing Weight/Set:16 KG



Frequently Asked Questions

What is the OSSDEN K35?

The K35 is an automatic sliding gate opener designed for heavy-duty sliding gates.

What is the maximum gate weight?

It is designed for sliding gates up to 1,800 kg.

What is the motor power?

The K35 uses a 750W motor.

What is the input voltage?

The published specification lists AC 230V/120V.

What is the torque of the K35?

The rated torque is 35 Nm.

What is the gate running speed?

The specified running speed is 12 m/min.

What type of transmission does it use?

It uses a turbine and turbine-rod transmission structure.

Does it have overheating protection?

Yes, the K35 includes an overheating protection function.

Can the gate be operated manually during a power failure?

Yes, it features a manual clutch/release mechanism for power-failure operation.

Is the K35 suitable for industrial gates?

Yes, its 1,800 kg capacity makes it suitable for large residential, commercial, and industrial sliding gates.

What is the operating temperature range?

The specified range is approximately -45°C to +65°C.

What is the protection rating?

The published K35 specification lists IP44 protection.

What is the noise level?

The specified noise level is ≤56 dB.

What is the remote-control range?

The listed remote-control distance is approximately 40–60 meters.

Can the K35 be used with safety sensors?

Yes, safety and access-control accessories such as infrared sensors can be integrated where applicable.

Can the K35 support additional accessories?

Yes, optional accessories include alarm lamps, infrared sensors, backup power, Bluetooth, vehicle remote control, mobile-phone control, and Wi-Fi.

Is the K35 easy to install?

It is designed for relatively straightforward installation with suitable mounting, rack alignment, and commissioning.

What is the gate opener size?

The published specification lists approximately 305 × 200 × 155 mm for the gate opener.

What is included with the standard kit?

The kit includes the gate motor, remote controls, brackets and hardware, instruction manual, clutch keys, limit magnets, fixing components, and related accessories.

What applications are suitable for the K35?

It is suitable for factories, warehouses, commercial buildings, residential compounds, villas, parking areas, and other heavy-duty sliding gate applications.
