Automatic Swing Gate
It is a wonderful feeling, to sit comfortably in your car while the gate opens itself. The process of getting out of the car just to open the gate seems rather cumbersome. And asides, should there be an emergency, the entire process could be disastrous. As a result of this, I thought it necessary to bring forward a review of the best gate opener.
Basically, InTrust electric gate opener is a practical device that automates the process of opening and closing of gates or the garage doors. There are various types of automatic gate openers that work effectively for various types of gates like the overhead doors, the swing gates, sliding gates, and the 2 leaf or single leaf gate.
The InTrust Remote Electric swing gate opener sets the gate to open or close automatically via a radio transmission without any human assistance. They can be powered either by 12/24 volts. More expensive are solar gate openers which are using solar power.
Product Videos
Swing Gate Motor 600Kg
| Model : | 690 |
| Input Voltage : | DC24V |
| Torque: | 8Nm |
| Rating Power: | 65W*2 |
| Remote Distance: | 40-60m |
| Rotation Speed: | 55rpm |
| Running Speed: | 0-15m/min |
| Noise: | ≤56dB |
| Dimension of Gate Opener: | 350*130*160mm |
| Dimension of Control Box: | 225*178*88mm |
| Packing Weight/Set: | 22kg |
| Temperature: | -45℃~+65℃ |
| Max. Gate Width: | ≤8m |
| Max. Gate Weight: | ≤600kg |
| Protection Class : | IP44 |
Swing Gate Motor 1000Kg
| Model : | T980 |
| Input Voltage : | DC24V |
| Torque: | 12Nm |
| Rating Power: | 100W*2 |
| Remote Distance: | 40-60m |
| Rotation Speed: | 50rpm |
| Running Speed: | 0-15m/min |
| Noise: | ≤56dB |
| Dimension of Gate Opener: | 370*200*165mm |
| Dimension of Control Box: | 225*178*88mm |
| Packing Weight/Set: | 32kg |
| Temperature: | -45℃~+65℃ |
| Max. Gate Width: | ≤8m |
| Max. Gate Weight: | ≤1000kg |
| Protection Class : | IP44 |
K280 Arm Type Electric Automatic Swing Gate Opener
| Model : | K280 |
| Input Voltage : | DC24V |
| Torque: | 8Nm |
| Rating Power: | 150W |
| Remote Distance: | 40-60m |
| Rotation Speed: | 55rpm |
| Running Speed: | 0-15m/min |
| Noise: | ≤56dB |
| Dimension of Gate Opener: | 340*168*178mm |
| Dimension of Control Box: | 620*300*500mm |
| Packing Weight/Set: | 31.2kg |
| Temperature: | -45℃~+65℃ |
| Max. Gate Width: | ≤8m |
| Max. Gate Weight: | ≤800kg |
| Protection Class : | IP54 |
A-750 Linear Swing Door Opener, ARM GATE OPENER
| Model : | A-750 |
| Input Voltage : | AC230V |
| Current: | 1.2A |
| Rating Power: | 150W |
| Remote Distance: | 40-60m |
| Thrust Force: | 400*3000N |
| Reduction Ratio : | 1/36 |
| Noise: | ≤56dB |
| Dimension of Gate Opener: | 993*126*88mm |
| Dimension of Control Box: | 225*178*88mm |
| Capacitor: | 10uF |
| Temperature: | -45℃~+65℃ |
| Max. Gate Width: | ≤8m |
| Max. Gate Weight: | ≤800kg |
| Protection Class : | IP54 |
Advantage Rolling Swing Gate Opener
- Smooth start and slow stop
- Automatically stop against extra resistances
- Optional operation mode for single or dual wing
- Available for Bluetooth / Mobile phone app control
- Interface for card reader and underground detector
- Large opening angle ＞180°
- Back-up power supply
Features and Benefits Swing Gate Motor
- Control your Gate through remote, push switch, wifi or keypad
- Smooth and soft start and stop function
- Emergency Discharge key in case of Electricity failure.
- Dual/Single gate running mode Optional master and slave gate running
- Adjustable opening/closing time interval between master and slave gate
- Can be Stop/Reverse in case of obstruction during gate opening/closing.
- The force of the motor can be programmed as per requirement.
- Optional photocell protection (If Required)
- Built in adjustable auto-close (As per Requirement)
DESCRIPTION CONTENT
The security issue is the biggest reason why people are more concerned about electric gates/industrial gate automation in Bangladesh. The InTrust automatic gates do not need any physical effort to open or close. It has security codes/remote at the side of the gate and visitors just need to input the code to the access control system to open the gate.
Automatic remote control gates are durable, strong and can be available in customized sizes. It is a first security system of your property, giving you a sense of security. For additional security, a mag-lock can be added to the door. A mag-lock is an electromagnet which is fuelled when the door is close. They can apply a power of 1500kg or more and in this way make it considerably harder to drive the entryway open. InTrust Automatic gates in Bangladesh provide a security to your kids who can play safe inside the property without any interference of outsiders.
It is very convenient to enter and leave the automatic gates. You can activate even you are 20-30 meters away from it. No longer have you had to come down from your cars to open your gates. InTrust will provide remote as per customer requirement in case you have more than one car.
