Automatic Hermetic Sliding Door for Hospitals & Operation Theatres
The Automatic Hospital Door & Hermetic Door is a specialized automatic door solution designed for hospitals, operation theatres, cleanrooms, laboratories, clinics and other controlled environments. The hermetic door system provides smooth automatic opening and closing while helping maintain cleanliness, hygiene, privacy and environmental control between different areas.
Designed for demanding healthcare applications, the automatic hospital door can be configured as a sliding or suitable specialty door system with automatic sensors, door operator, control system and safety features. Its sealed design is particularly suitable for areas where minimizing air leakage, dust movement and contamination is important.
The system is suitable for hospitals, medical centers, operating rooms, ICUs, laboratories, pharmaceutical facilities and cleanroom environments in Bangladesh.
Door Profile – 1 Pcs
Automatic Door Operator – 1 set
Top Cover – 1 Pcs
Door Hanging Assembly – 1 set
Door Hanger – 1 set
Belt – 1 Pcs
Pully – 1 Pcs
Stopper – 2 Pcs
Motion/Presence Sensor – 1 or 2 pcs
Door Control Unit – 1 set
| Gate sliding modes | single open/double open |
| Door weight | 1X100-195kg / 2X80-185kg (As per Needs) |
| Clean opening width: | 600-1500mm/1200-1800mm |
| Power supply voltage | AC 220V ± 10%, 50/60Hz |
| Power consumption: | <180W |
| Opening speed | 300mm-600mm/s (adjustable) |
| Closing speed | 300mm-600mm/s (adjustable) |
| Open time | 0-9s (adjustable) |
| Ambient temperature | -20 ~ +50℃ |
| Manual opening force | <50N |
| Open style | Foot sensor (As per Requirement) |
Door Dimension: Custom manufactured as per site requirements. Standard clear opening width approximately 800–2,400 mm and clear opening height approximately 2,000–2,500 mm. Final door dimensions, panel thickness, operator capacity and sealing arrangement shall be determined according to site conditions, door weight, wall construction and project requirements.
Common Sizes
900 × 2100 mm – single door
1200 × 2100 mm – single/sliding application
1500 × 2100 mm – wide single sliding door
1600 × 2100 mm – double sliding door
1800 × 2100 mm – double sliding door
2000 × 2200 mm – wider hospital entrance
2400 × 2400 mm – large specialized opening
Frequently Asked Questions
What is an automatic hospital door?
An automatic hospital door is a motorized door system designed for healthcare facilities. It can open and close automatically using sensors, push buttons or other access-control devices.
What is a hermetic door?
A hermetic door is a specially designed door system that creates a tighter seal around the doorway when closed. It is commonly used in environments where controlling airflow, dust and contamination is important.
Where are hermetic doors commonly used?
Hermetic doors are commonly used in operation theatres, hospitals, cleanrooms, laboratories, isolation areas, pharmaceutical facilities and medical treatment rooms.
Is an automatic hermetic door suitable for operation theatres?
Yes. Hermetic automatic doors are commonly specified for controlled healthcare environments such as operation theatres, subject to the required project specifications and applicable standards.
How does an automatic hospital door operate?
The door can be activated through suitable sensors, push buttons, access-control systems or other compatible activation devices. The automatic operator then opens and closes the door according to its programmed settings.
Does a hermetic door help control air leakage?
A properly designed and installed hermetic door can help reduce unwanted air leakage around the closed doorway. Actual performance depends on the door construction, seals, installation and pressure conditions.
Can hermetic doors be used in cleanrooms?
Yes. Hermetic doors are suitable for certain cleanroom applications where controlled access and reduced air leakage are required. The specific door specification should be selected according to the cleanroom classification and project requirements.
Are automatic hospital doors suitable for ICUs?
They can be used in healthcare areas such as ICUs when the selected door system meets the project's operational, hygiene, safety and access requirements.
What type of activation can be used?
Depending on the system, activation can include motion sensors, touchless switches, push buttons, access-control systems, remote controls or other compatible devices.
Can the door be operated manually during a power failure?
Many automatic door systems can incorporate a manual release or emergency operating arrangement. The exact emergency function depends on the selected operator and project specification.
Are hermetic doors available in sliding configurations?
Yes. Automatic hermetic sliding doors are widely used where space-efficient operation and controlled sealing are required.
What materials are used for hospital doors?
Depending on the design, hospital and hermetic doors can be manufactured using suitable metal panels, stainless steel, coated steel, aluminum and other hygienic or project-approved materials.
Can automatic hospital doors be customized?
Yes. Door dimensions, finish, activation method, hardware, access control and other features can be specified according to the building design and application.
Where can I install an automatic hermetic door in Bangladesh?
The system can be considered for hospitals, clinics, diagnostic centers, medical laboratories, pharmaceutical facilities, cleanrooms and other controlled environments throughout Bangladesh.
Is professional installation required?
Yes. Professional installation is recommended to ensure correct door alignment, sealing, sensor positioning, electrical connections, automatic operation and commissioning.
Related products
DESCRIPTION
The InTrust Automatic Hospital Door / Airtight Door / ICU Door / Hermetic doors forms part of the solutions offered by our team for laboratories, hospitals, laboratory, lazaretto ward, purification plant, pharmaceutical industries and environments related to the health sector. Our airtight sliding doors are customizable. Finished in stainless steel or high pressure laminate which is available in a wide range of colours, as well as the combination of both. With bi-part or single-slide options, InTrust ICU Door / hermetic door for hospitals are combine the advantages of an automatic door with the air-tightness and hygiene required for clean environments. This makes our designs perfectly integrated into any architectural project, adding aesthetic value that conveys professionalism, elegance and safety to users. InTrust hermetic sliding doors carry our seal of guarantee, as they ensure access, comfort and provide maximum security. There is an option for a flush-surfaced vision panel in glass with camera, elegantly designed and easy to clean, all available in different shapes and sizes.
The door body is made of colorised steel panel with foaming process or made of the large-plane sub-light stainless steel plate and framed large-plane glass. At both sides and the center joint, there are the sealing strips installed, which conforms to the sanitary requirement for use in automatic hospital door, research institute, recording studio or any other places need for dust proof and cleanness. Special purpose seal stripe are used to seal around the mobile door to make sure that the door will joint tightly with the doorframe for air tightness when closed. It can join the door frame when close down and ensuring the airtightness of door
