Automatic Sliding Gate
It is an amazing feeling, to sit comfortably in your car while the gate opens itself. The process of getting out of the car just to open the gate seems rather difficult. Basically, an electric remote control gate opener is a practical device that automates the process of opening and closing of gates or the garage doors. InTrust various types of automatic gate operator/electric gate motor that work effectively for various types of gates like the overhead doors, the swing gates, sliding gates and the 2 leaf or single leaf of industrial sliding gate automation.
Product Videos
Z30T AC 4000KG Automatic Sliding Gate Opener, 3 Phase
| Model : | Z30T |
| Input Voltage : | AC380V (3 Phase) |
| Torque: | 35Nm |
| Rating Power: | 1100W |
| Remote Distance: | 40-60m |
| Rotation Speed: | 1400rpm |
| Running Speed: | 14m/min |
| Noise: | ≤56dB |
| Dimension of Gate Opener: | 495*205*315mm |
| Carton Size: | 495*205*315mm |
| Packing Weight/Set: | 36kg |
| Temperature: | -45℃~+65℃ |
| Max. Gate Width: | ≤20m |
| Max. Gate Weight: | ≤4000kg |
| Protection Class : | IP44 |
Z30 AC 3000KG Automatic Sliding Gate Opener, 1 Phase
| Model : | Z30 |
| Input Voltage : | AC220V (Single Phase) |
| Torque: | 35Nm |
| Rating Power: | 750W |
| Remote Distance: | 40-60m |
| Rotation Speed: | 1400rpm |
| Running Speed: | 14M/min |
| Noise: | ≤56dB |
| Dimension of Gate Opener: | 495*205*315mm |
| Carton Size: | 575*340*315mm |
| Packing Weight/Set: | 36kg |
| Temperature: | -45℃~+65℃ |
| Max. Gate Width: | ≤20m |
| Max. Gate Weight: | ≤3000kg |
| Protection Class : | IP44 |
K45 Remote Control Sliding Gate Opener, OSSDEN
| Model : | K45 |
| Input Voltage : | AC230V (Single Phase) |
| Torque: | 45Nm |
| Rating Power: | 1200W |
| Remote Distance: | 40-60m |
| Rotation Speed: | 1400rpm |
| Running Speed: | 12M/min |
| Noise: | ≤56dB |
| Dimension of Gate Opener: | 305*200*155mm |
| Carton Size: | 320*270*375mm |
| Packing Weight/Set: | 16.3kg |
| Temperature: | -45℃~+65℃ |
| Max. Gate Width: | ≤15m |
| Max. Gate Weight: | ≤2500kg |
| Protection Class : | IP44 |
K35 Remote Control Sliding Gate Opener, OSSDEN
| Model : | K45 |
| Input Voltage : | AC230V (Single Phase) |
| Frequency: | 50HZ |
| Rating Power: | 750W |
| Remote Distance: | 40-60m |
| Rotation Speed: | 1400rpm |
| Running Speed: | 12M/min |
| Noise: | ≤56dB |
| Dimension of Gate Opener: | 305*200*155mm |
| Carton Size: | 320*270*375mm |
| Packing Weight/Set: | 13.4kg |
| Temperature: | -45℃~+65℃ |
| Max. Gate Width: | ≤15m |
| Max. Gate Weight: | ≤1800kg |
| Protection Class : | IP44 |
Sliding Gate Opener, INTRUST
| Model : | SG-A-019 |
| Input Voltage : | AC230V (Single Phase) |
| Torque: | 35-45Nm |
| Rating Power: | 550W/750W/1200W |
| Remote Distance: | 40-75m |
| Rotation Speed: | 1400rpm |
| Running Speed: | 12M/min |
| Noise: | ≤56dB |
| Dimension of Gate Opener: | 305*200*155mm |
| Carton Size: | 320*270*375mm |
| Packing Weight/Set: | 13.6kg/14.7kg /15.3 kg |
| Temperature: | -45℃~+65℃ |
| Max. Gate Width: | ≤15m |
| Max. Gate Weight: | 1200kg/1800kg/2200kg |
| Protection Class : | IP4 |
Sliding Motor, Nice, Italy
Phase: Single Phase
Type of Motor: DC
Speed: 3-5 Seconds Per Mtr
Operating Temperature: – 20 degree to + 50 degree
Power: 700-1000 Watts
Maximum Weight Weight:1500/1800/2000/2500 Kg
Sliding Gate Operator teeth
Steel rack should be used on all gates exceeding 800kg or where a large slope is present, as it will provide a more positive mesh with drive pinion and will also provide a longer service life for both the rack and your motor
Security beam sensor
Detection technology: Infrared
Range: 15m
Frequency: 1.92Khz
Power: 12-24V AC/DC
Wave Length: 940mm
Input: RX 15mA, TX 30mA
Operating temperature: -20 to 70 degrees
Relay output: 1Amp max 30V
Dimension: 49.2 x 76 21mm
- The security issue is the biggest reason why people are more concerned about electric gates/industrial gate automation in Bangladesh. The InTrust automatic gates do not need any physical effort to open or close. It has security codes/remote at the side of the gate and visitors just need to input the code to the access control system to open the gate.
- Automatic remote control gates are durable, strong and can be available in customized sizes. It is a first security system of your property, giving you a sense of security. For additional security, a mag-lock can be added to the door. A mag-lock is an electromagnet which is fuelled when the door is close. They can apply a power of 1500kg or more and in this way make it considerably harder to drive the entryway open. InTrust Automatic gates in Bangladesh provide a security to your kids who can play safe inside the property without any interference of outsiders.
- It is very convenient to enter and leave the automatic gates. You can activate even you are 20-30 meters away from it. No longer have you had to come down from your cars to open your gates. InTrust will provide remote as per customer requirement in case you have more than one car.
