High Speed Swing Turnstile Apple Shape for university

Product Videos

Supply Voltage	110V-240V, AC, 50HZ
Motor	DC 24V/40W
Working temperature	－35℃ ～ 60℃
Relative humidity	≤95%, No Condensation
Input Interface	Relay input
Drive mode	Pulse signal
Motor	Brushless motor
Access width	600mm
NO mode	60p/m
NC mode	30p/m
Communication Interface	RS485/Relay signal
Size	L 1200W200H930mm
Running direction	Full automatic single direction, bi-direction(optional)
Encoder digital positioning, more precise
Anti-hit mechanism
Apple shape design, widely used for kindergarten

What is the suitable application for this swing turnstile?

It is ideal for universities, schools, kindergartens, offices, and controlled access areas.

Is this turnstile safe for children?

Yes, the apple shape design with anti-hit mechanism makes it safe and friendly for kindergartens and students.

What power supply does the turnstile support?

It supports 110V–240V AC power with DC 24V brushless motor for stable performance.

How fast is the passing speed of the turnstile?

The passing speed is up to 60 persons per minute in NO mode and 30 persons per minute in NC mode.

Can this turnstile integrate with access control systems?

Yes, it supports RS485 and relay interfaces and can connect with card readers, QR, fingerprint, and access control systems.
